Laminated Bus Bar

Photovoltaic Applications - Laminated Busbar

Laminated busbar is a connection bar with a multi-layer composite structure. Compared to the traditional complex wiring methods used, laminated busbar provides a highly technical and easily designed distribution system with a clear structure. It is characterized by repeatable electrical performance, low inductive impedance, high interference immunity and high reliability, and can therefore used as an electrical connection component for some high-power modules.

Features

· A new tensile structure is used at the IGBT contact (simplifies installation); a new tensile structure is used at the capacitor contact (simplifies installation)

Photovoltaic Laminated Busbar

Item	Parameters
Voltage	1000V DC
Current	1200A
Insulation withstand voltage	3.0 KV -AC-60s, no breakdown, no flicker (leakage current<5mA)
Partial discharge	+/- AC1.1KV(≤10PC), +/N, -/NAC550V(≤10PC)

Photovoltaic Laminated Busbar

Item	Parameters
Voltage	1000V DC
Current	600A
Insulation withstand voltage	3.5 KV -DC-60s, no breakdown, no flicker (leakage current<2mA)

Photovoltaic Laminated Busbar

Item	Parameters
Voltage	1000V DC
Current	1285A
Insulation withstand voltage	5.0 KV -DC-60s, No breakdown, no flicker (leakage current ≤ 2mA)
Partial discharge	AC 900V(＜10 pC)
